Anycubic Photon Mono 4 Ultra

$259.00
$299.00 $259.00
-$40.00
Shipping calculated at checkout.

Product Features
● 7'' 10K screen (9024x5120 resolution) with 17x17μm pixel size
● Advanced COB Light Source and Fresnel Lens
● Intelligence Assisted Printing System
● Faster Printing: 0.1mm at max. 120mm/h with High Speed Resin 2.0
🐰 Easter Special Bundle: For Extra Wash & Cure 3 Only $69!
⚡ Pay $1 Extra Gets You 1KG Resin!
Include Wash&Cure Machine: None
Include Resin: None
Shipping & Adapter: US
🚚 Ships in 24 hours

Free Express Shipping

14-Day No Reason Return

30-Day After-Sales Guarantee

One-Year Warranty For 3D Printers

100% Secure Payment

$259.00
$299.00 $259.00
ANYCUBICAnycubic Photon Mono M7 Pro
Anycubic Photon Mono M7 Pro
Anycubic Photon Mono 4
ANYCUBICAnycubic Photon Mono 4

Photon Mono 4 Ultra Video

Why Choose Photon Mono 4 Ultra

  • 10K Precision, Almost Detail-Perfect

  • Great Laser, Great Lens, Great Layer

  • There's No Resin to Print Slow

  • Intelligent Release Algorithm

  • Intelligent 360° Self-Check

  • Activated Carbon Air Purifier Compatible
10K Precision, Almost Detail-Perfect.
Printing with 0.02mm Layer Height
105% precision increase compared to Mono 2
X/Y-axis pixel precision reaches 17*17 μm
Level Up & Speed Up.
Great Laser, Great Lens, Great Layer
High Precision and Light Uniformity
New Generation of Release Film
Save 40% on print time, boost 100% of your spirit
Level Up & Speed Up.
There's No Resin to Print Slow.
0.1mm Layer Height Test Standard
Standard Resin: Max. 80mm/h
High Speed Resin 2.0: Max. 120mm/h*
*Experience high-speed printing under the most challenging printing conditions, even with a layer height at just 0.1mm
Intelligent 360° Self-Check.
Failed Print Monitoring
Resin Residue Monitoring
Resin Level Monitoring
Release Film Lifespan Management
Printer Monitoring
Intelligent 360° Self-Check.
Activated Carbon Air Purifier Compatible.
The 18 mm high-density activated carbon filter, weighing 17 grams, is designed to efficiently capture and neutralize odor molecules produced during printing.
*Activated Carbon Air Purifier sold separately
All-new Advance Resins.
High Speed Resin 2.0: Resilient Against Bending and Cracking
Texture Resin: Produces Excellent Details
Bio Resin: Eco-friendly
All-new Advance Resins.
The Anycubic Software Ecosystem
The Anycubic app
The Anycubic Photon WorkShop
Makeronline creativity community

Specification

Tech specs

  • Build volume

    153.4mm*87mm*165mm

  • Machine dimensions

    231mm*236mm*430mm

  • Printing speed

    Standard Resin 0.1mm layer height: 80mm/h peek speed; High Speed Resin 0.1mm layer height: 120mm/h peek speed

  • Machine leveling

    4-point manual leveling

  • Lcd screen size

    7-inch 10K Mono LCD

  • Light source

    COB light source+ Fresnel lens+Light uniformity algorithm

  • Xy resolution

    17*17μm

  • Operating screen

    4.3" TFT touch-control

  • Slicing software

    Photon Workshop

  • Material

    Supports most resins on the market (water-washable, standard, bio resin, plant-based, etc.)

  • File transfer

    USB & WiFi & LAN MODE (Q4)

  • Machine weight

    5KG

  • Light uniformity

    ≥90%

  • Release film

    ACF

  • Light intensity

    ≥3500μW /cm²

  • Layer height

    0.02-0.15mm

  • Package dimensions

    512mm*300mm*305mm

  • Air purifier

    USB

  • Anycubic app

    Support

  • Intelligence assisted printing system

    Support

Products Comparison

Picture Photon Mono 4 Photon Mono 4 Ultra
Printer Model Photon Mono 4 Ultra Photon Mono 4
Build Volume 153.4mm*87mm*165mm 153.4mm*87mm*165mm
Product Dimensions 231mm*236mm*430mm 230mm*235mm*391mm
Packaging Dimensions 512mm*300mm*305mm 480mm*300mm*300mm
Net Weight 5KG 4KG
Printing Speed Standard Resin 0.1mm Layer Thickness Peak speed 80mm/h | High Speed Resin 0.1mm Layer Thickness Peak speed 120mm/h Standard Resin 0.1mm Layer Thickness Peak speed ≤50mm/h | High Speed Resin 0.1mm Layer Thickness Peak speed ≤70mm/h
Layer Height 0.02-0.15mm 0.03-0.15mm
LCD Screen 7-inch Mono LCD 7-inch Mono LCD
Printing Resolution 10K 10K
X/Y Axis Resolution 17*17um 17*17um
Light Source COB light source+ Fresnel lens+Light uniformity algorithm Parallel matrix upgrade light source
Light Uniformity ≥90% 80-90%
Full-Stage Intelligent Assisted Printing System √ ×
Light Intensity ≥3500μW /cm² ~3000μW /cm²
Release Film ACF FEP
AirPure Optional(USB) Optional(Rechargeable)
Display Screen 4.3" TFT touch-control 2.8" TFT touch-control
Anycubic App √ ×
Machine leveling 4-point manual leveling 4-point manual leveling
Slicing Software Photon Workshop Photon Workshop
File Transfer USB & WiFi& LAN MODE(Q4) USB

In The Box

  • Photon Mono 4 Ultra

  • Print Platform * 1

  • Resin Vat * 1

  • Manual * 1

  • Sreen Protector Kit

  • Leveling paper

  • Glove

  • Funnels

  • Scrapers

  • Hex Key Set

  • USB Drive

  • Power Cord

FAQs

A: For more information on the Photon Mono 4 Ultra, please visit the Anycubic Wiki.

A：The Light Uniformity Algorithm ensures uniform light exposure across all layers, with a uniformity rate of ≥90%. This reduces dimensional errors, delivering consistent and high-quality prints even on larger models.

A: The advanced COB light source, combined with a Fresnel lens, ensures precise light distribution with an angle of only 3°. This eliminates stray light interference and provides uniform illumination, improving print detail and accuracy.

The new ACF film reduces surface texture, allowing for better light penetration and smoother resin release. This results in faster print times and higher print success rates, reducing the chance of layer separation.

A: The overall rated power of the machine is 66W.

With Anycubic's High Speed Resin 2.0, the Photon Mono 4 Ultra can reach a printing speed of up to 120mm/h at 0.1mm layer height, a 60% speed increase over its predecessor. Standard resin can print at a maximum of 80mm/h.

The Photon Mono 4 Ultra features failed print detection that monitors anomalies like cracks, detachment, or layer separation. When issues are detected, the printer pauses and notifies the user, helping prevent wasted resin and time.

You can print highly detailed models, miniatures, and complex designs with ease. The combination of 10K resolution and precise optical adjustments ensures models with intricate details and smooth surfaces.

The printer includes residual resin detection and automatic resin level monitoring. It will alert users to clean any solid residues in the vat and notify them when the resin level is too low for the next print.

1. Adapt to the official slicing software, which supports vector slicing;
2. Compatible with Chitu, Tangoo and Lychee slicing software, slicing mode aligned with WorkShop, vector format turned off.
