16K Standard Resin
Couldn't load pickup availability
16K High-Precision with Low-Shrinkage Rate
Featuring an advanced Molecular Cross-Linking formulation, Anycubic 16K Standard Resin drastically reduces shrinkage during the curing process. This ensures a 1:1 recreation of your original digital designs, making it the premier choice for high-precision mechanical components and hyper-detailed miniatures.
Refined Matte Texture without Vertical Lines
This special formulation significantly reduces vertical lines, delivering a premium matte finish straight from the build plate. Achieve a smooth and excellent texture without the need for manual buffing or extensive post-processing.
High-Hardness against Deformation
Formulated with high-rigidity monomers, Anycubic 16K Standard Resin provides superior structural stability. Its high-hardness profile allows for ultra-thin walls and slender geometries that resist warping and sagging. This exceptional resistance to mechanical stress ensures long-term reliability for load-bearing applications.
Premium Colors without Color Difference
Anycubic sources only the finest color pigments to ensure every bottle of resin delivers pure, saturated color. Our precision-tuned photoinitiator system eliminates muddy, grayish undertones and frustrating color variations, ensuring your prints remain vibrant without being cheap or plasticky.
Minimal Odor & Eco-Friendly
Anycubic resin features a specially engineered low-odor formulation, delivering zero irritation for a pleasant, comfortable printing experience.
Wide Compatibility
Compatible with all 405nm UV-curing LCD/DLP 3D printers onthe market, while delivering optimal print performance when pairedwith Anycubic LCD 3D printers.
Download
Color Type
Recommended Printing Parameters - Orange Red
| Printer Model | Layer Thickness | Exposure Time | Light-Off Time | Bottom Exposure Time | Bottom Layers | Anti-Aliasing Level | Z Lift Distance | Z Lift Speed | Z Retract Speed |
| Photon P1 | 0.05 mm | 2.8 s | 2 s | 30 s | 1 | 4 | 5 mm | 3 mm/s | 3 mm/s |
| Photon Mono M7 | 0.05 mm | 2.8 s | 0.5 s | 80 s | 15 | 1 | 8 mm | 6 mm/s | 6 mm/s |
| Photon Mono M7 Pro | 0.05 mm | 2.8 s | 0.5 s | 80 s | 15 | 1 | 8 mm | 6 mm/s | 6 mm/s |
| Photon Mono M7 Max | 0.05 mm | 2.8 s | 0.5 s | 80 s | 15 | 1 | 8 mm | 6 mm/s | 6 mm/s |
| Photon Mono M5 | 0.05 mm | 2.8 s | 0.5 s | 60 s | 10 | 1 | 8 mm | 6 mm/s | 6 mm/s |
| Photon Mono M5s | 0.05 mm | 3 s | 0.5 s | 60 s | 10 | 1 | 8 mm | 6 mm/s | 6 mm/s |
| Photon Mono M5s Pro | 0.05 mm | 3.6 s | 1 s | 60 s | 12 | 1 | 8 mm | 6 mm/s | 6 mm/s |
| Photon Mono 4 | 0.05 mm | 2.8 s | 0.5 s | 60 s | 8 | 1 | 6 mm | 4 mm/s | 6 mm/s |
| Photon Mono 4K | 0.05 mm | 2.5 s | 0.5 s | 60 s | 10 | 1 | 6 mm | 4 mm/s | 6 mm/s |
| Photon Mono 4 Ultra | 0.05 mm | 2.5 s | 0.5 s | 50 s | 6 | 1 | 5 mm | 8 mm/s | 8 mm/s |
| Photon Mono 2 | 0.05 mm | 2.5 s | 1 s | 60 s | 12 | 1 | 6 mm | 4 mm/s | 6 mm/s |
| Photon Mono X2 | 0.05 mm | 2.5 s | 0.5 s | 60 s | 12 | 1 | 8 mm | 2 mm/s | 3 mm/s |
| Photon Mono X 6K | 0.05 mm | 2.5 s | 0.5 s | 80 s | 12 | 1 | 8 mm | 2 mm/s | 3 mm/s |
| Photon Mono X 6Ks | 0.05 mm | 2.5 s | 0.5 s | 80 s | 10 | 1 | 8 mm | 2 mm/s | 3 mm/s |
| ANYCUBIC Photon Mono M3 Max | 0.05 mm | 3 s | 2 s | 80 s | 12 | 1 | 10 mm | 4 mm/s | 4 mm/s |
| ANYCUBIC Photon Mono M3 Premium | 0.05 mm | 2.5 s | 0.5 s | 60 s | 10 | 1 | 8 mm | 6 mm/s | 6 mm/s |
*When printing with 16K Standard Resin (Orange Red), it is recommended to apply the recommended parameters to effectively ensure an excellent first layer and reduce the risk of print failure. Ambient temperature affects resin viscosity and print quality, requiring parameter adjustments:
Summer (>30°C without AC/temperature control):
*Reduce standard exposure time by 0.5-1s.
*Reduce base layer exposure time.
Winter (<10°C without AC/temperature control):
*Increase standard exposure time by 0.5-1s.
*Increase base layer exposure time.
Recommended Printing Parameters - Other 4 Colors
| Printer Model | Layer Thickness | Exposure Time | Light-Off Time | Bottom Exposure Time | Bottom Layers | Anti-Aliasing Level | Z Lift Distance | Z Lift Speed | Z Retract Speed |
| Photon P1 | 0.05 mm | 2.5 s | 2 s | 20 s | 1 | 4 | 5 mm | 3 mm/s | 3 mm/s |
| Photon Mono M7 | 0.05 mm | 2.3 s | 0.5 s | 40 s | 5 | 1 | 8 mm | 6 mm/s | 6 mm/s |
| Photon Mono M7 Pro | 0.05 mm | 2 s | 0.5 s | 40 s | 5 | 1 | 8 mm | 6 mm/s | 6 mm/s |
| Photon Mono M7 Max | 0.05 mm | 2.5 s | 0.5 s | 45 s | 5 | 1 | 8 mm | 6 mm/s | 6 mm/s |
| Photon Mono M5 | 0.05 mm | 2.8 s | 0.5 s | 40 s | 6 | 1 | 8 mm | 6 mm/s | 6 mm/s |
| Photon Mono M5s | 0.05 mm | 3 s | 0.5 s | 40 s | 5 | 1 | 8 mm | 6 mm/s | 6 mm/s |
| Photon Mono M5s Pro | 0.05 mm | 3.6 s | 1 s | 40 s | 5 | 1 | 8 mm | 6 mm/s | 6 mm/s |
| Photon Mono 4 | 0.05 mm | 2.8 s | 0.5 s | 45 s | 5 | 1 | 6 mm | 4 mm/s | 6 mm/s |
| Photon Mono 4K | 0.05 mm | 2 s | 0.5 s | 40 s | 6 | 1 | 6 mm | 4 mm/s | 6 mm/s |
| Photon Mono 4 Ultra | 0.05 mm | 2.5 s | 0.5 s | 40 s | 5 | 1 | 5 mm | 8 mm/s | 8 mm/s |
| Photon Mono 2 | 0.05 mm | 2.5 s | 1 s | 40 s | 5 | 1 | 6 mm | 4 mm/s | 6 mm/s |
| Photon Mono X2 | 0.05 mm | 2.5 s | 0.5 s | 40 s | 5 | 1 | 8 mm | 2 mm/s | 3 mm/s |
| Photon Mono X 6K | 0.05 mm | 2 s | 0.5 s | 45 s | 6 | 1 | 8 mm | 2 mm/s | 3 mm/s |
| Photon Mono X 6Ks | 0.05 mm | 2.5 s | 0.5 s | 45 s | 6 | 1 | 8 mm | 2 mm/s | 3 mm/s |
| ANYCUBIC Photon Mono M3 Max | 0.05 mm | 3 s | 2 s | 50 s | 6 | 1 | 10 mm | 4 mm/s | 4 mm/s |
| ANYCUBIC Photon Mono M3 Premium | 0.05 mm | 2.5 s | 0.5 s | 45 s | 3 | 1 | 8 mm | 6 mm/s | 6 mm/s |
Ambient temperature affects resin viscosity and print quality, requiring parameter adjustments:
Summer (>30°C without AC/temperature control):
*Reduce standard exposure time by 0.5-1s.
*Reduce base layer exposure time.
Winter (<10°C without AC/temperature control):
*Increase standard exposure time by 0.5-1s.
*Increase base layer exposure time.
Instructions for Use
1. Before use:
Shake liquid resin well
Clean resin vat and build plate
Ensure vat bottom remains highly transparent
Confirm release film is undamaged
Verify correct print parameter settings
Recommended printing environment: 20-35 °C (to prevent temperature-related failures)
2. During Use:
Unscrew bottle cap and remove sealing film
Pour resin into vat without exceeding max fill line
3. After Printing:
Use included tools for post-processing:
Scraper / Flush cutters / Tweezers / Gloves / ≥95% IPA cleaning solution
4. Post-Processing:
A. Remove models from build plate using a scraper; remove supports
B. Clean models in Anycubic Wash & Cure machine for ~10 minutes (use ≥95% alcohol or cleaner)
C. Dry models: Air-dry, blow-dry, or use drying chamber (prevents water absorption/cracking)
D. Secondary curing: Cure models for 3-5 minutes
E. Resin recycling: Filter through a 100-mesh sieve
Precautions
- Store at room temperature away from light
- Recommended use temperature: >20°C (low temperatures reduce success rate; high temperatures accelerate pigment settling)
- If pigment settles: Stir with plastic scraper or shake resin bottle
- Resin cures under sunlight: Print in dim, ventilated areas or cover printer
- Remove models promptly after washing to avoid property degradation
- Always wear nitrile gloves and goggles (avoid skin/eye contact)
- Waste disposal: Cure resin completely before discarding as solid waste
- Maintain ventilation; keep liquid away from pregnant women, children, and pets
Notes
Material properties may vary based on: Printing equipment, Post-curing methods, Testing instruments
For safety data/certifications (MSDS, REACH, RoHS, EAN, TDS): Refer to product documentation
Contact us with any issues
