UV Tough Resin

$39.99
$49.99 $39.99
-$10.00
Shipping calculated at checkout.

Product Features
● High Toughness, Not Easy to Break
● Good Tensile Strength and Elongation
● High Precision, Low Shrinkage
UV Tough Resin has been delisted.
Click here to learn about the UV Tough Resin 2.0
Size: 1KG
Shipping to: US
Color: Clear
🚚 Ships in 24 hours
🚚 UK - Black/White - Estimated Delivery Time: Dec. 1st - Dec. 10th
🚚 CA - Gray - Estimated Delivery Time: Dec. 21st - Dec. 31st
🚚 AU - Clear/Translucent green/White - Estimated Delivery Time: Dec. 20th- Dec. 31th
🏷 Random Colors : Shipped randomly based on inventory.

Free Express Shipping

14-Day No Reason Return

30-Day After-Sales Guarantee

One-Year Warranty For 3D Printers

100% Secure Payment

$39.99
$49.99 $39.99
ANYCUBICWater-Wash Resin+
Water-Wash Resin+
PLA High Speed
ANYCUBICPLA High Speed

Resin Parameters

UV wavelength 365-405nm Elongation at break 30-50%
Density 1.10-1.15g/cm³ Tensile modules of elasticity 800-1200MPa
Viscosity 150-250MPa·s（25℃） Flexural strength 35-45MPa
Felxural modulus >900-1200 MPa Hardness 76 Shore D
Heat deflection temp >60-65℃ Tensile strength 50-60 MPa
IZOD Impact Strength >50-60J/m Heat Deflection Temperature 60℃(0.45MPa)
Resin wash Alcohol Conservation period 1.5 Year

Model Print

Recommended Printing Parameters

Printer Model Layer Thickness Exposure Time Light-Off Time Bottom Exposure Time Bottom Layer Anti-Aliasing Level Z Lift Distance Z Lift Speed Z Retract Speed
Photon Mono M7 Pro 0.05mm 2s 2s 25s 4 1 8mm 6mm/s 6mm/s
Photon Mono M5s Pro (Normal printing mode) 0.05mm 3s 0.5s 30s 5 1 8mm 6mm/s 6mm/s
Photon Mono M5s Pro (Fast printing mode) 0.1mm 3.4s 0.5s 30s 4 1 5mm 20mm/s 20mm/s
Photon Mono M5s (Normal printing mode) 0.05mm 3.6s 0.5s 30s 5 1 8mm 6mm/s 6mm/s
Photon Mono M5s (Fast printing mode) 0.1mm 4s 0.5s 30s 5 1 5mm 20mm/s 20mm/s
Photon Mono M5 0.05mm 3s 0.5s 30s 5 1 8mm 6mm/s 6mm/s
Photon M3 Max 0.05mm 3s 2.5s 50s 6 1 10mm 2mm/s 3mm/s
Photon Mono X 6Ks 0.05mm 2.5s 0.5s 20s 5 1 8mm 2mm/s 3mm/s
Photon Mono X2 0.05mm 2.5s 1s 20s 5 1 8mm 2mm/s 3mm/s
Photon Mono 2 0.05mm 2.5s 1s 25s 5 1 6mm 4mm/s 6mm/s
Photon D2 0.05mm 2.5s 1s 28s 5 1 5mm 2mm/s 3mm/s
Photon M3 Plus 0.05mm 1.5s 0.1s 23s 3 1 6mm 6mm/s 6mm/s
Photon M3 0.05mm 3s 0.5s 23s 4 1 6mm 3mm/s 4mm/s
Photon M3 Premium 0.05mm 2.5s 1s 25s 2 1 8mm 6mm/s 6mm/s
Photon Ultra / / / / / / / / /
Photon Mono X 0.05mm 2s 0.5s 28s 4 1 8mm 2mm/s 3mm/s
Photon Mono 4K 0.05mm 2.3s 0.5s 40s 6 1 6mm 4mm/s 6mm/s
Photon Mono X 6K 0.05mm 2s 0.5s 23s 6 1 8mm 2mm/s 3mm/s
Photon Mono SQ 0.5mm 2.3s 0.5s 23 6 1 5mm 3mm/s 3mm/s
Photon Mono SE 0.05mm 1.5s 0.5s 30s 6 1 6mm 4mm/s 6mm/s
Photon Mono 0.05mm 2s 0.5s 40s 6 1 6mm 4mm/s 6mm/s
Photon S 0.05mm 8s 1s 60s 6 1 6mm 3mm/s 3mm/s

Color Type

Instructions for Use

(1) Before use:
Shake the liquid resin before use;
Clean the resin tank and the molding platform to keep the bottom of the resin tank in light
transmission.

(2) When using:
Unscrew the cap and add it to the resin tank according to the equipment requirements;
Select the correct print parameters and settings for printing.

(3) After use:
After printing, please use the matching tools for post-processing, including blade, diagonal
pliers,tweezers,containers,gloves;
ethanol(≥95%),lactate or isopropyl alcohol cleaning solution;

(4) Post-processing steps:
A. Remove the printed model from the molding platform with a blade;
B. Submerge the model in the cleaning solution, rinsed or ultrasonically washed, then taken
out and drained; ANYCUBlC Wash and Cure machines are suggested to ensure better effect.
C.Proper processing, such as removing support, polishing, coloring, etc.

Precautions

  1. The ideal condition for storing uncured resin is a cool, dark place at room temperature and protect from light
    to avoid high temperature or sunlight.
  2. Suggested operating temperature is 18-35'c, and a low temperature may affect the printing effect, thus, the
    resin can be properly preheated before use (not more than 60°C).
  3. If the resin pigment settles, it can be used after stirring or shaking.
  4. In order to ensure the performance of the resin, please take out the model in time after cleaning to avoid the model soaking in water for a long time.
  5. To ensure the mechanical properties of the model, please perform post-curing in time after cleaning and drying.
  6. To ensure the ideal performance of the curable material, it is necessary to control the intensity and time of the
    light source after curing.Therefore, the following steps are recommended:
    (1) The intensity of mercury lamp or LeD light source is 5-10mW/m?, and the duration is no more than 1 hour (self-regulation);
    (2)The exposure time in the sun (summer) is around 1 hour;
    (3) Proximity or long-term exposure under strong light sources such as high-power high-pressure mercury
    lamps is prohibited.
    (4) lt is recommended to print in a dark room or be covered with a lid while printing as resin is a photosensitive
    material.


Ps: Material properties willvary depending on the molding equipment, post-curing method and testing equipment. For safetyinformation
please refer to the MSDS of this product. lf you encounter any problems while using, please feel free to contact us.

FAQs

What models are suitable for printing with UV Tough Resin?

UV Tough Resin is designed for parts that need to be bent repeatedly and can recover their shape, jigs and fixtures requiring repeated deflection, extrudable prototypes, low-friction components, and buffering, damping, and shock-absorbing parts.

Does it have a strong odor? What can be used to clean and cure the models?

UV Tough Resin has a distinct odor and can be cleaned with isopropyl alcohol. For curing purposes, it's advisable to use a Wash & Cure Machine .

WhiWhere can I find the recommended printing parameters for Anycubic's printers when using UV Tough Resin?

You can view the recommended printing parameters on this details page. If you do not find the results you want, please contact our support team for answers.

Where can I download the MSDS file?

Click here to download the MSDS of the resin.

If I buy 3KG of resin, will I receive a 3KG bottle of resin?

When you purchase 3KG of resin, you will receive three 1KG bottles, not one single 3KG bottle. This applies to other quantities as well.

Where can I download the model for free?

Click here to download the free model.

What should I do if my model keeps failing to print?

Click here to download the free model.If you are unable to print or printing fails, please contact our support team for answers.

What should I do if I receive resin that is leaking?

If your resin is leaking, it might have been damaged during transportation. Please take pictures of the product you received and contact our customer support team. They will assist you in resolving the issue.
