Anycubic Photon Mono X 6K (Limited Edition)

Regular price $659.00
Regular price Sale price $659.00
Shipping calculated at checkout.

Free Express Shipping

14-Day No Reason Return

30-Day After-Sales Guarantee

One-Year Warranty For 3D Printers

100% Secure Payment

Regular price $659.00
Regular price Sale price $659.00

Product Description


Fast printing speed
Photon Mono X can print a typical 12cm / 4.7in. model in 1.5 hours.
High light transmittance
High light transmittance makes quick forming possible.
Large build volume
print up to 9.6 x 7.8 x 4.8 in. / 24.5 x 19.7 x 12.2 cm (HWD) at a time.
Sharp edges and corners
Adopting an industry-leading screen with 350:1 contrast ratio.
anycubic photon mono X printer
Technical Specifications
● Exposure screen: 9.25’’ monochrome
● Printing volume: 199.1 oz. / 1.6 gal. / 5.9 L
● Light transmittance: 6%
● Contrast ratio: 350:1
● Light source: Parallel matrix (LED x 40)
● Power density: 5,000 - 6,500 μw/cm² / 34,150 - 44,395 lux
● Printing accuracy: 5,760 x 3,600 px (6K)
● Horizontal resolution: 34 μm
● Printing speed: Max 80mm/h
● Control panel: 3.5’’ TFT touch-control
● Data input: USB-A 2.0 / LAN
● Power supply: 120W
● Screen area: 38.22 in² / 248.75 cm²
● Machine dimensions: 18.7 x 11.4 x 10.6 in. / 47.5 x 29 x 27 cm (HWD)
● Machine weight: 24.3 lb. / 11 kg
For Freedom to Make
Anycubic Photon Mono X 6K can print up to 9.6 x 7.8 x 4.8 in. / 24.5 x 19.7 x 12.2 cm (HWD) at a time, similar dimensions to a super midi rugby ball. 199.1 oz. / 1.6 gal. / 5.9 L total build volume leaves more space and freedom for you to make any shapes of cubic.
6K Vivid Details
With 5,760 x 3,600 px resolution, Anycubic Photon Mono X 6K's screen has a total number of over 20 million pixels, which is 125% higher than Anycubic Photon Mono X and its rivals' 4K resolution screen. High resolution brings vivid details to your 3D models.
Sharp Edges and Corners
Adopting an industry-leading screen with 350:1 contrast ratio, 75% higher than Anycubic Photon X and its rivals' 200:1, Anycubic Photon Mono X 6K provides your 3D models with extremely sharp and clear edges and corners.
Protect What Matters
In order to better protect its premium screen, Anycubic Photon Mono X 6K added a dedicated and replaceable anti-scratch film above the screen itself, making that expensive screen much more durable than its rivals.
Print, One Step Ahead
With an impressive print speed at ≤ 8 cm/hr. / 3.15 in./hr., Photon Mono X can print a typical 12cm / 4.7in. model in 1.5 hours, which takes 4.5 hours less than Photon's 6 hours, and 1.5 hours less than its rivals' 3 hours. Fast printing saves your time wasted on waiting.
Powerful Light Matrix
40 bright LED lights are placed into a matrix to make up a powerful and parallel light source, so that Anycubic Photon Mono X 6K can provide ≥90% light uniformity and ≤ 44,395 lux power density to each layer, making fast printing possible.
High Light Transmittance
Anycubic Photon Mono X 6K is equipped with an industry leading screen with 6% light transmittance, which is 200% higher than Anycubic Photon Mono X and its rivals' 2%. High light transmittance makes quick forming possible.
Universal Compatibility
With 30%-100% light power regulation, Anycubic Photon Mono X 6K supports not only ordinary 405nm UV resins, but also special resins. In addition, adjusting the light power appropriately can extend the lifespan of both the screen and light significantly.
9.25'' Large Screen
Anycubic Photon Mono X 6K is equipped with a large 9.25'' screen, which is 185% larger than Anycubic Photon's 5.5'' screen, 138% larger than a common 6'' screen, and 8% larger than Photon Mono X and its rivals' 8.9'' in screen area.
Parts List
User Manual
Funnel
Tool set
SD-Card Reader
Scraper
Resin Vat
Platform
Power Cord
LCD Screen Protector
Mask
Glove

    Photon Mono X
   Photon Mono 4K
   Photon Mono X 6k
Machine Weight 10.8kg 4.3kg 11kg
Machine Size 475x290x270mm 383x227x222mm 475x290x270mm
LCD Resolution 3840x2400px(4k) 3840x2400px(4k) 5760x3600px(6k)
LCD Size 8.9’’ monochrome 6.23’’ monochrome 9.25’’ monochrome
XY Resolution 50 microns 35 microns 34 microns
Z axis Accuracy 10 microns 10 microns 10 microns
Build volume 245xx192x120mm(5.6L) 165x132x80mm(1.74L) 245x197x122mm(5.89L)
Max.Printing Speed 60mm/h 50mm/h 80mm/h
  • anycubic photon
    Photon
    LCD-based SLA
    Build Area: 115x65x155mm
    Filament:405nm UV Resin
    Diffusion Illuminant
    Single Z-axis
  • anycubic photon s
    Photon S
    LCD-based SLA
    Build Area: 115x65x165mm
    Filament:405nm UV Resin
    Matrix Illuminant
    Double Z-axis
  • 4Max Pro
    FDM (Fused Deposition Modeling)
    Build Area: 270x205x205mm
    Filament: PLA, ABS, HIPS, PETG,
    Wood and TPU
    Titan Extruder
    Suspended Filament Rack
    Single Z-axis
