$158.99

~~$359.90~~ $158.99

US / 10KG / Gray

Highlight

Name: Plant-Based UV Resin 10-100kg Deals
Brand: ANYCUBIC
Price: 158.99 USD
Availability: InStock
Rating: 5 (8 reviews)

Anycubic Plant-based Resins are made from soybean extracts which are green and natural. They are safe and environmentally friendly photosensitive resins.
No chemical irritating odor that will easily cause physical discomfort. And printing with them at any time and anywhere.
Optimized curing time for Anycubic Resin 3D Printers, offering better printing quality.
Sensitive to 355nm~405nm UV light. Compatible with most LCD/DLP 3D printers.

Anycubic Plant-Based UV Resin

Ultralow odor without nasty chemicals

Resin Parameters

UV wavelength	355nm-410nm	Elongation at break	8-12%
Solid Density	1.05-1.25g/cm³	Bending strength	40-50 MPa
Viscosity	150-350 MPa·s (25°C)	Shrinkage	1.88-2.45%
Thermal deformation	>55±5℃	Hardness	89D
Vitrification Temp	>60±5℃	Thermal Expansion	95*E-6
Extension Strength	35-45 MPa	Conservation period	1.5 Year

Model Print

Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layer	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon Mono M7 Pro	0.05mm	2s	0.5s	25s	4	1	8mm	6mm/s	6mm/s
Photon Mono M5s Pro (Normal printing mode)	0.05mm	3.6s	0.5s	30s	5	1	8mm	6mm/s	6mm/s
Photon Mono M5s Pro (Fast printing mode)	0.1mm	4s	0.5s	30s	5	1	5mm	20mm/s	20mm/s
Photon Mono M5s (Normal printing mode)	0.05mm	2.8s	0.5s	25s	5	1	8mm	6mm/s	6mm/s
Photon Mono M5s (Fast printing mode)	0.1mm	3.2s	0.5s	25s	4	1	5mm	20mm/s	20mm/s
Photon Mono M5	0.05mm	2.8s	0.5s	25s	5	1	8mm	6mm/s	6mm/s
Photon M3 Max	0.05mm	3s	2.5s	50s	6	1	10mm	2mm/s	3mm/s
Photon Mono X 6Ks	0.05mm	2.5s	0.5s	20s	5	1	8mm	2mm/s	3mm/s
Photon Mono X2	0.05mm	2.5s	0.5s	20s	5	1	8mm	2mm/s	3mm/s
Photon Mono 2	0.05mm	2.5s	1s	25s	5	1	6mm	4mm/s	6mm/s
Photon D2	0.05mm	2.5s	1s	28s	5	16	5mm	2mm/s	3mm/s
Photon M3 Plus	0.05mm	1.5s	0.1s	23s	6	1	6mm	6mm/s	6mm/s
Photon M3	0.05mm	3s	0.5s	23s	4	1	6mm	3mm/s	4mm/s
Photon M3 Premium	0.05mm	2s	0.5s	25s	2	1	8mm	6mm/s	6mm/s
Photon Ultra	/	/	/	/	/	/	/	/	/
Photon Mono X	0.05mm	2s	0.5s	28s	4	1	8mm	2mm/s	3mm/s
Photon Mono 4K	0.05mm	2s	0.5s	40s	6	1	6mm	4mm/s	6mm/s
Photon Mono X 6K	0.05mm	2.3s	0.5s	23s	6	1	8mm	2mm/s	3mm/s
Photon Mono SQ	0.05mm	2.3s	0.5s	23s	6	1	5mm	3mm/s	3mm/s
Photon Mono SE	0.05mm	1.5s	0.5s	30s	6	1	6mm	4mm/s	6mm/s
Photon Mono	0.05mm	2s	0.5s	40s	6	1	6mm	4mm/s	6mm/s
Photon S	0.05mm	8s	1s	60s	6	1	6mm	3mm/s	3mm/s

Resin Color

Instructions for Use

(1) Before use:
Shake the liquid resin before use;
Clean the resin tank and the molding platform to keep the bottom of the resin tank in light
transmission.

(2) When using:
Unscrew the cap and add it to the resin tank according to the equipment requirements;
Select the correct print parameters and settings for printing.

(3) After use:
After printing, please use the matching tools for post-processing, including blade, diagonal
pliers,tweezers,containers,gloves;
ethanol(≥95%),lactate or isopropyl alcohol cleaning solution;

(4) Post-processing steps:
A. Remove the printed model from the molding platform with a blade;
B. Submerge the model in the cleaning solution, rinsed or ultrasonically washed, then taken
out and drained; ANYCUBlC Wash and Cure machines are suggested to ensure better effect.
C.Proper processing, such as removing support, polishing, coloring, etc.

Precautions

The ideal condition for storing uncured resin is a cool, dark place at room temperature and protect from light
to avoid high temperature or sunlight.
Suggested operating temperature is 18-35'c, and a low temperature may affect the printing effect, thus, the
resin can be properly preheated before use (not more than 60°C).
If the resin pigment settles, it can be used after stirring or shaking.
In order to ensure the performance of the resin, please take out the model in time after cleaning to avoid the model soaking in water for a long time.
To ensure the mechanical properties of the model, please perform post-curing in time after cleaning and drying.
To ensure the ideal performance of the curable material, it is necessary to control the intensity and time of the
light source after curing.Therefore, the following steps are recommended:
(1) The intensity of mercury lamp or LeD light source is 5-10mW/m?, and the duration is no more than 1 hour (self-regulation);
(2)The exposure time in the sun (summer) is around 1 hour;
(3) Proximity or long-term exposure under strong light sources such as high-power high-pressure mercury
lamps is prohibited.
(4) lt is recommended to print in a dark room or be covered with a lid while printing as resin is a photosensitive
material.

Ps: Material properties willvary depending on the molding equipment, post-curing method and testing equipment. For safetyinformation
please refer to the MSDS of this product. lf you encounter any problems while using, please feel free to contact us.

FAQs

What models are suitable for printing with Plant-Based UV Resin?

Plant-Based UV Resin is perfect for printing animation and game action figures, architectural models, rapid prototyping structural parts, and appearance prototypes, especially in environments sensitive to resin odor or without ventilation.

Does it have a strong odor? What can be used to clean and cure the models?

Plant-Based UV Resin is basically odorless. For curing, please consider purchasing a Wash & Cure Machine .

Where can I find the recommended printing parameters for Anycubic's printers when using Plant-Based UV Resin?

You can view the recommended printing parameters on this details page. If you do not find the results you want, please contact our support team for answers.

Where can I download the MSDS file?

Click here to download the MSDS of the resin.

If I buy 3KG of resin, will I receive a 3KG bottle of resin?

When you purchase 3KG of resin, you will receive three 1KG bottles, not one single 3KG bottle. This applies to other quantities as well.

Where can I download the model for free?What should I do if my model keeps failing to print?

If you are unable to print or printing fails, please contact our support team for answers.

What should I do if I receive resin that is leaking?

If your resin is leaking, it might have been damaged during transportation. Please take pictures of the product you received and contact our customer support team. They will assist you in resolving the issue.
