Optimize Resin 3D Printing: Anycubic Plant Based Resin Settings

Anycubic plant-based resin is made from soybean oil, which is environmentally friendly and has a much lower odor than regular resins. With the development of 3D printing technology, 3D printing materials are also being upgraded in an attempt to be greener and safer, which is why Anycubic plant-based resin is chosen by users. In order to fully utilize the potential of resin materials, users are usually required to set appropriate printing parameters, such as layer height, exposure time, z-axis lifting speed, etc. This not only optimizes the performance of the printer, but also helps to improve the quality of the 3D prints, allowing users to obtain ideal models. In this guide, we will introduce Anycubic plant-based resin and provide detailed printing parameters.


Overview of Anycubic Plant Based Resin

Anycubic plant-based resin attempts to meet users' needs for environmentally friendly resin materials. It is made from soybean extract, BPA-free, does not contain benzene and benzene harmful substances, non-irritating, no VOCs volatilization, and is a resin material that complies with EN 71-3:2013. Considering the user experience of Anycubic plant-based resin, it can meet the user's demand for high-quality printing, has reliable stability, and has a mild smell during use, so there is no need to worry about a strong smell. It is important to note that direct skin contact should be avoided during the resin printing process, and that safety measures and ventilation are still necessary.

  • Made from soybean oil, environmentally friendly.
  • No VOCs, low odor.
  • Short curing time.
  • 3D Print has a smooth surface, high precision, and good strength and flexibility.


Anycubic Plant Based Resin Settings: Recommended Print Parameters

Printing parameters can control key aspects such as layer thickness, exposure time, support structure, and more. During the printing process, the resin printer will run according to instructions, which is directly related to the printing parameters set by the user. Setting the right print parameters has a positive impact on print quality, print detail, layer adhesion, etc. Users can also adjust and customize printing parameters as needed to obtain the best results. Resin settings and print parameters are equally important when using Anycubic plant-based resins. In the following, the recommended print parameters for Anycubic plant-based resins will be provided, which users can refer to, use, or adjust to achieve consistent and fine quality prints.

Plant Based Resin Layer Thickness Normal Exposure Time Off Time Bottom Exposure Time Bottom Layers Z Lift Distance Z Lift Speed Z Retract Speed
Photon Mono 0.05 mm 2 s 0.5 s 40 s 6 6 mm 4 mm/s 6 mm/s
Photon Mono X 0.05 mm 2 s 0.5 s 28 s 4 8 mm 2 mm 3 mm/s
Photon Mono X 6K 0.05 mm 2.3 s 0.5 s 23 s 6 8 mm 2 mm/s 3 mm/s
Photon Mono 4K 0.05 mm 2.3 s 0.5 s 40 s 6 6 mm 4 mm/s 6 mm/s
Photon M3 0.05 mm 3 s 0.5 s 23 s 4 6 mm 3 mm/s 4 mm/s
Photon M3 Plus 0.05 mm 1.5 s 0.5 s 23 s 6 6 mm 6 mm/s 6 mm/s
Photon M3 Max 0.05 mm 3 s 2.5 s 50 s 6 10 mm 2 mm/s 3 mm/s
Photon M3 Premium 0.05 mm 2.5 s 0.5 s 25 s 2 8 mm 6 mm/s 6 mm/s
Photon Mono X2 0.05 mm 2.5 s 0.5 s 20 s 5 8 mm 2 mm/s 3 mm/s
Photon Mono 2 0.05 mm 2.5 s 1 s 25 s 5 6 mm 4 mm/s 6 mm/s
Photon Mono X6Ks 0.05 mm 2.5 s 0.5 s 20 s 5 8 mm 2 mm/s 3 mm/s
Photon Mono M5 0.05 mm 2.8 s 0.5 s 25 s 5 8 mm 6 mm/s 6 mm/s
Photon Mono M5s 0.05 mm 3.6 s 0.5 s 25 s 5 8 mm 6 mm/s 6 mm/s
Photon D2 0.05 mm 2.5 s 1 s 28 s 5 5 mm 2 mm/s 3 mm/s

In Conclusion: Optimal 3D Printing with Anycubic Resin

By adjusting and controlling printing parameters, users can optimize the effect of 3D prints according to their needs. With Anycubic plant-based resin, you can refer to the printing parameters recommended by the parameter to realize the balance of printing quality and efficiency. Anycubic plant-based resin is a reliable and environmentally friendly resin with excellent material properties, worthy of user choice and exploration. Please use it in a well-ventilated environment and take protective measures. The product should be stored in an airtight container and sealed promptly after use, not exposed to sunlight, also please avoid humid environment.
