Anycubic Photon M3 Premium

Regular price $399.00
Regular price $639.00 Sale price $399.00
-$240.00
Shipping calculated at checkout.

If you want to buy Resin 3D Printer, please click here to view the latest models.
Shipping To: EU

Free Express Shipping

14-Day No Reason Return

30-Day After-Sales Guarantee

One-Year Warranty For 3D Printers

100% Secure Payment

Regular price $399.00
Regular price $639.00 Sale price $399.00

Product Description

8K High Resolution
28.5μm XY Resolution.
Anycubic LighTurbo 2.0
Brand New Released Light Source Technology.
10" Monochrome LCD Screen
380:1 High Contrast Ratio.
Ball Screw Double Threaded Rods
95mm/hour Max Printing Speed.
Technical Specifications
● ZAxis: Double liners with 5 μm accrace
● Resin Tank: Unibody design with scale lines
● Build Platform: Laser Carved Metal
● Exposure Screen: 10.1" monochrome(7680x4320 px, 28.5μm XY Resolution)
● Light Source: Anycubic LighTurb 2.0 Light Source
● Power Supply: 150W rated power
● Control Panel: 4.3" TFT touch-control
● Data input: USB Type-A2.0/ Wi-Fi Port
● Machine Leveling: 4-point manual leveling
● Printing Speed: ≤95 mm or 3.7in./hr.
● Printing Volume: 6.7L/226.5oz.
● Machine Dimensions: 25*13*14 in. / 630*330*350 mm (HWD)
● Printing Dimensions: 9.9*4.9*8.6 in. / 250*123*219 mm(HWD)
● Machine Weight: 19kg / 41lb.

*Before using Anycubic APP, download the updated firmware if the printer firmware version is 1.0.2.0 or lower.
8K High Precision Resolution
Designed with a 10-inch monochrome LCD screen with a 7680x4320 resolution and an XY-resolution of 28.5μm, respectively 216% and 40% higher than the Anycubic Photon Mono 4K. The models' sharp corners and delicate edges are perfectly printed, revealing the beauty of sharper details.
Details Beyond 8K
The patented self-innovated LightTurbo 2.0 light source solution provides the high light uniformity of the COB light source system while eliminating stray light, creating a delicate and smooth model surface.
Upgraded Cooling System
The combination of software and hardware automatically detects the temperature. It adjusts the speed of the cooling fan according to ensure that the printing environment is kept within 65℃, effectively improving the light source’s lifespan.
Large Volume Brings Unlimited Creativity
The printing size of Anycubic Photon M3 Premium is 250*220*120 mm (HWD), and the maximum printing volume reaches 6.7L, which provides more creative space for creators while ensuring printing accuracy.
Stable Double Threaded Rods
Compared to the T-shaped threaded rod, the ball screw double-threaded rods provide 0.005mm of improved structural accuracy, which is only half of the ordinary T-shaped rod printer, significantly reducing the layer line effects. The double-threaded rods minimize the lifting resistance of the platform while printing by adopting the rolling friction principle, making the printing speed even faster.
Anycubic App | 3D Printing in just One Touch
With Anycubic APP, users can select models, slice online, print in one touch, and monitor printing progress with their smartphones. Anycubic APP, which allows you to print anywhere, anytime and feel the fun of realizing your creativity with just one touch, also comes with a practical help center. Anycubic APP is available on Google Play, App Store, Anycubic official website.
Efficient Air Purification
The double air-purifiers system is embedded with high-density activated carbon inside the air purifiers. The symmetrical double air intake design enlarges the air inlet and outlet area by 1.5 times, achieving 80% odor removal within 10 minutes.
Larger Vat, Less Refill
A 60% larger resin tank eliminates the need to refill resin constantly when printing large 3D models. Compared to traditional FEP film, the application of NFEP film make it easier to detach the prints, increasing the printing success rate by 10%.
Unlimited Applications
Anycubic Photon M3 Premium 3D printer can easily meet various printing needs, enabling lower cost, larger volume, and higher precision model printing.


Parts List
Funnel
Glove
Mask
Tool set
Platform
Power-cord
Resin Vat
Scraper
User manual
USB memory
Screen protector
Levelling paper
WIFI Antenna
AirPure

   Photon M3 Premium
   Photon M3 Plus
   Photon M3 Max
Machine Weight 19kg 11kg 21kg
Machine Size 630x330x350mm 475*290*360mm 596*400*408mm
LCD Resolution 7680x4320px(8k) 5760x3600px (6k) 6480x3600px (7k)
LCD Size 10.1’’ monochrome 9.25’’ monochrome 13.6’’ monochrome
XY Resolution 28.5 microns 34 microns 46 microns
Z axis Accuracy 5 microns 10 microns 10 microns
Build volume 250x123x219mm(6.7L) 245*197*122mm(5.9L) 300*298*164mm(14.7L)
  • Photon M3
    7,6" 4K+ LCD
    Build volume [LxBxH]: 163 x 102 x 180 mm
    Material: 405nm UV Resin
    Printing speed: 50mm/h
  • Photon M3 Plus
    9,25" 6K LCD
    Build volume [LxBxH]: 197 x 122 x 245 mm
    Material: 405nm UV Resin
    Printing speed: 100mm/h
  • Photon M3 Max
    13,6" 7K LCD
    Build volume [LxBxH]: 425 x 269 x 256 mm
    Material: 405nm UV Resin
    Printing speed: 60mm/h
